16/24-Port 100M Long-Range PoE Switch Quick Start Guide
3
The 1000M RJ45 port is transmitting data.
No 1000M RJ45 port connected or connection is abnormal.
The SFP fiber optical port is connected.
The SFP fiber optical port is transmitting data.
No SFP fiber optical port connected or connection is abnormal.
RJ45 port is transmitting data.
RJ45 port is disconnected or connection is abnormal.
The switch provides power supply to PD normally.
The switch is disconnected to PD, or provides power supply to PD
abnormally.
The output power of the switch is about to reach the upper limit.
The power supply may be abnormal if more devices are connected.
The switch provides power supply to PD normally.
DIP Switch
DIP switch can be switched to two statuses: standard model, and extend model.
Table 1-3 DIP Switch Model
The corresponding port supports network transmission of
up to 100 m, and the speed rate of the port is 100 Mbps.
Extend
DS-3E0318P-E/M(B): Extend (9-16)
DS-3E0326P-E/M(B): Extend (17-24)
The 9 to 16 ports of DS-3E0318P-E/M(B) and the 17 to 24
ports of DS-3E0326P-E/M(B) support network transmission
of up to 250 m, and the speed rate of the port is 10 Mbps.
PoE Ports
100M PoE ports are used for other PoE devices connection via network cables.
Ensure that your devices powered via the PoE port have their shells protected and fire-proofed,
because the switches are not compliant with the Limited Power Source (LPS) standard.
G1 Port/G2 Port
G1 port is a 1000M RJ45 port used for other devices connection via network cables.
G2 port is a 1000M SFP fiber optical port used for other devices connection via optical fiber
when plugged into with an optical module.
