16/24-Port 100M Long-Range PoE Switch Quick Start Guide
3
No 1000M combo connected or connection is abnormal.
The port is transmitting data.
The port is disconnected or connection is abnormal.
The switch provides power supply to PD normally.
The switch is disconnected to PD, or provides power supply to PD
abnormally.
The output power of the switch will reach the upper limit. The
power supply may be abnormal if more devices are connected.
The switch provides power supply to PD normally.
DIP Switch
DIP switch can be switched to three statuses: standard model, extend model, and aggregation
model.
Table 1-3 DIP Switch Model
The corresponding port supports network transmission of up to
100 m, and the speed rate of the port is 100 Mbps.
Extend
DS-3E0318P: Extend (9-16)
DS-3E0326P: Extend (17-24)
The 9 to 16 ports of DS-3E0318P and the 17 to 24 ports of
DS-3E0326P support network transmission of up to 250 m, and the
speed rate of the port is 10 Mbps.
The aggregation function of the corresponding port is enabled, and
the 1000M port link aggregates. The two physical ports become a
logical port with 2G bandwidth.
PoE Ports
100M PoE ports connect to other PoE devices with network cable.
Ensure that your devices powered via the PoE port have their shells protected and fire-proofed,
because the switches are not compliant with the Limited Power Source (LPS) standard.
1000M Combos
When connected to a network cable, the 1000M combo is a PoE port. When plugged into with
an optical module and connected to an optical fiber, the 1000M combo functions as a fiber
optical interface.
