HIKVISION DS-3E2300P Series Quick Start Guide

16/24-Port 100M Long-Range PoE Switch Quick Start Guide
4
 When connected to both the network cable and optical fiber at the same time, the port works
as a fiber optical interface.
1.3.2 Rear Panel
Rear panel of DS-3E0318P and DS-3E0326P is shown as below.
Rear Panel of DS-3E0318P and DS-3E0326P
Figure 1-3 DS-3E0318P and DS-3E0326P Rear Panel
Grounding Terminal
The grounding terminal connects with ground cable in case of lightning. For details about
grounding, see section Grounding.
Power Interface
Connect power interface of the switch with power socket by power cord, and use 220 VAC to
provide power to the switch.
Please use the original power cord to power up the switch.
