HIKVISION DS-7108NI-SN/P Quick Operation Guide

Quick Operation Guide of Network Video Recorder
36
Specifications of DS-7600NI-SE/P
Model
DS-7604NI-SE/P
DS-7608NI-SE/P
DS-7616NI-SE/P
Video/Audio
input
IP video input
4-ch
8-ch
16-ch
Two-way audio input
1-ch, RCA (2.0 Vp-p, 1kΩ)
Network
Incoming bandwidth
20Mbps
40Mbps
80Mbps
Output bandwidth
40Mbps
Remote connection
32
128
128
Video/Audio
output
Recording resolution
5MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
HDMI/VGA output
1-ch, resolution:
1920 × 1080P /60Hz, 1600 × 1200 /60Hz, 1280 × 1024 /60Hz, 1280 × 720 /60Hz,
1024 × 768 /60Hz
CVBS
(optional)
1-ch, BNC (1.0 Vp-p, 75 Ω)
Resolution: 704 × 576 (PAL); 704 × 480 (NTSC)
Audio output
1-ch, RCA (Linear, 1kΩ)
Playback resolution
5MP /3MP /1080P /UXGA /720P /VGA /4CIF /DCIF /2CIF /CIF /QCIF
Synchronous
playback
4-ch@720P,
2-ch@1080P,1-ch@5MP
8-ch@4CIF, 4-ch@720P, 2-ch@1080P, 1-ch@5MP
Hard disk
SATA
2 SATA interfaces for 2 HDDs
Capacity
Up to 4TB for each disk
External
interface
Network interface
1 RJ-45 10 /100 /1000 Mbps self-adaptive Ethernet interface
Serial interface
1 RS-485 half-duplex interface
USB interface
2 × USB 2.0
Alarm in/out
(optional)
4/1
PoE
Interface
4 independent 10 /100 Mbps PoE Ethernet interfaces
8 independent 10 /100
Mbps PoE Ethernet
interfaces
Output Consumption
52W
120W
Supported Standard
AF
Others
Power supply
100~240VAC, 47~63Hz, 3A
Consumption
≤ 15 W (without hard disk)
Working
temperature
-10 ºC ~ +55 ºC (14 ºF ~ 131 ºF )
Working humidity
10 % ~ 90 %
Chassis
19-inch rack-mounted 1U chassis
Dimensions
(W × D × H)
445 × 290 × 45mm (17.5 × 11.4 × 1.8 inch)
Weight
≤ 2 Kg ( without hard disk)

HIKVISION DS-7108NI-SN/P Specifications

General

Brand	HIKVISION
Model	DS-7108NI-SN/P
Category	Network Hardware
Language	English
