HIKVISION DS-7208HGHI-SH Quick Start Guide

1 2 S E T U P R E C O R D I N G ( c o n t i n u e d )
13 P L A Y B A C K R E C O R D E D V I D E O
Video playback plays back recorded video.
1. Go to MENU>PLAYBACK.
2. Select the desired camera from the drop-down menu.
3. Select the desired date (days that contain recordings will be highlighted).
4. Select the desired time using the Timeline or “Jump to Time” feature.
5. Press PLAY.
 Play Back Record Files
1. Choose a camera in Live View and click the button in the shortcut operation menu. Only
files recorded in the past five minutes will be played.

SUBSTREAM TAB
Select
 CAMERA
Select camera
 STREAM TYPE
Select choice
 RESOLUTION
Can go up only to 4CIF
 VIDEO QUALITY
Select number of green squares
to set quality (in example,
sensitivity is set to 3)
SUBSTREAM TAB

SMART SEARCH/
PLAYBACK
Search for specific defined
activities
FULL SCREEN
Goes to full screen for multiple
channel playback
PLAY/STOP
Begin playback (toggles between
Play and Stop)
CAMERA LIST
Select camera to play back
CALENDAR
Select date to play back
TIMELINE
Click on timeline to select desired
playback time






















HIKVISION DS-7208HGHI-SH Specifications

General

Product color	Black
Channels quantity	8 channels
Total storage capacity	12000 GB
Video compression formats	H.264
Playback resolutions supported	1920 x 1080, 1280 x 1024, 1280 x 720, 1024 x 768
Audio input	1
BNC input ports	8
USB 2.0 ports quantity	2
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, PPPoE, DHCP, DNS, DDNS, NTP, SADP, SMTP, SNMP, NFS, iSCSI, UPnP, HTTPS
HDD interface	Serial ATA
Power requirements	12V DC
Power consumption (typical)	20 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Dimensions (WxDxH)	315 x 242 x 45 mm
