HIKVISION DS-7216HQHI-K1 User Manual

Digital Video Recorder User Manual
232
Model
DS-7204HUHI-K1/P
DS-7208HUHI-K2/P
CVBS input
PAL/NTSC
PoC camera
input
Supports Hikvision PoC camera
Note: Do not unplug or plug the PoC camera if it is powered by the
external power supply.
IP video input
2-ch
Up to 6 MP resolution
Supports H.265+/H.265/H.264+/H.264 IP cameras
Audio
compression
G.711u
Audio input
4-ch, RCA (2.0 Vp-p, 1 KΩ)
Video/Audio
output
CVBS output
1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 ×
480
HDMI/VGA
output
1-ch, 1920 × 1080/60Hz, 1280 ×
1024/60Hz, 1280 × 720/60Hz,
1024 × 768/60Hz
VGA: 1-ch, 1920 × 1080/60Hz,
1280 × 1024/60Hz, 1280 ×
720/60Hz, 1024 × 768/60Hz
HDMI: 1-ch, 4K (3840 ×
2160)/30Hz, 2K (2560 ×
1440)/60Hz, 1920 × 1080/60Hz,
1280 × 1024/60Hz, 1280 ×
720/60Hz, 1024 × 768/60Hz
Encoding
resolution
5 MP/4 MP/3 MP/1080p/720p/WD1/4CIF/VGA/CIF
Frame rate
Main stream:
5 MP@12fps/4 MP@15fps/3 MP@18fps
1080p/720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N)
Sub-stream:
WD1/4CIF/CIF@25fps (P)/30fps (N)
Video bit rate
32 Kbps to 10 Mbps
Audio output
1-ch, RCA (Linear, 1 KΩ)
Audio bit rate
64 Kbps
Dual stream
Support
Stream type
Video, Video & Audio

HIKVISION DS-7216HQHI-K1 Specifications

General

Product color	Black
Channels quantity	16 channels
Playback resolutions supported	1920 x 1080, 1280 x 1024, 1280 x 720, 1024 x 768, 3840 x 2160, 2560 x 1440
Audio input	RCA
BNC input ports	16
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN	Yes
Ethernet interface type	Gigabit Ethernet
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS, ONVIF
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Power consumption (typical)	25 W
HDD interface	Serial ATA
Maximum HDD capacity	6000 GB

Weight and Dimensions

Weight	2000 g
Dimensions (WxDxH)	315 x 242 x 45 mm
