User Manual of Digital Video Recorder
102
Figure 6. 6 Video Search by Motion Detection
4.
Click
Search
, and the record files matching the search conditions will be displayed on a list.
5.
Select and click button to play back the record files.
You can click
Back
to return to the search interface.
If there is only one channel triggered, clicking button takes you to Full-screen Playback interface of
this channel.
If several channels are triggered, clicking button takes you to the synch playback interface. Check
checkbox to select one channel for playback or select multiple channels for synchronous playback.
The max. number of channels for synchronous playback supported varies to different models.
Figure 6. 7 Select Channels for Synchronous Playback
