User Manual of Digital Video Recorder
163
12.2 Searching and Exporting Log Files
Purpose:
The operation, alarm, exception and information of the DVR can be stored in log files, which can be viewed and
exported at any time.
Steps:
1. Enter the Log Search interface.
Menu > Maintenance > Log Search
Figure 12. 7 Log Search Interface
2. Set the log search conditions to refine your search, including the Start Time, End Time, Major Type and
Minor Type.
3. Click the Search button to start search log files.
4. The matched log files will be displayed on the list shown below.
Up to 2000 log files can be displayed each time.
Figure 12. 8 Log Search Results
5. You can click the button of each log or double-click it to view its detailed information, as shown in
Figure 12. 9. And you can also click the button to view the related video files if available.
