User Manual of Digital Video Recorder
48
3. Double-click the preset you want to call in the Preset list.
4.2.3 Customizing Patrols
Purpose:
Patrols can be set to move the PTZ to a set of different key points sequentially and have it stay there for a set
duration before moving on to the next key point. The key points are corresponding to the presets. The presets
can be set following the steps above in Customizing Presets.
Steps:
1. Enter the PTZ Control interface.
Menu>Camera>PTZ>More Settings
2. Select patrol number.
3. Select the under Patrol option box to add key points for the patrol.
Figure 4. 6 PTZ- Add Key Point
4. Configure key point parameters, such as the key point No., duration of staying for one key point and speed
of patrol. The key point is corresponding to the preset.
The Preset determines the order at which the PTZ will follow while cycling through the patrol.
The Duration refers to the time span to stay at the corresponding key point.
The Speed defines the speed at which the PTZ will move from one key point to the next.
Figure 4. 7 Key point Configuration
5. Click OK to save the key point to the patrol.
