User Manual of Digital Video Recorder
24
1.5 Rear Panel
Figure 1. 8 DS-7204HFHI-SL
Figure 1. 9 DS-7208HFHI-SL
Figure 1. 10 DS-7204HFHI-SE
Figure 1. 11 DS-7204HFHI-ST
Figure 1. 12 DS-7208HFHI-SE and DS-7208HFHI-ST
No.
Item
Description
1
VIDEO IN
HD-SDI interface for video input.
2
AUDIO IN
RCA connector
3
AUDIO OUT
RCA connector
4
VGA
DB15 connector for VGA output. Display local video output and menu.
