Digital Video Recorder Quick Start Guide
4
Chapter 1 Rear Panel Interfaces Description
The rear panel interfaces vary with different models. Refer to Table 1-1 for the common interfaces description
of rear panels.
Table 1-1 Common Interfaces Description of Rear Panels
Chapter 2 Installation and Connections
2.1 DVR Installation
During installation of the DVR:
Use brackets for rack mounting.
Ensure ample room for audio and video cables.
When routing cables, ensure that the bend radius of the cables are no less than five times than its
diameter.
Connect the alarm cable.
Allow at least 2 cm (≈0.75-inch) of space between racks mounted devices.
Ensure the DVR is grounded.
Environmental temperature should be within the range of -10 to +55º C, +14 to +131º F.
Environmental humidity should be within the range of 10% to 90%.
BNC interface for Turbo HD and analog
video input
BNC connector for video output
Connector for two-way audio input
Universal Serial Bus (USB) port
for additional devices
DB15 connector for VGA output.
Displays local video output and menu.
HDMI video output connector
Connector for RS-485 devices
Connector for RS-232 devices
Storage and expansion interface
for record or backup
Connector for alarm input/output
Switch for turning on/off the device
100 to 240 VAC, 48 VDC, or 12
VDC for different models
