Digital Video Recorder Quick Start Guide
10
3.7 Adding IP Cameras
Purpose
Before you can get live video or record the video files, you should add the network cameras to the connection
list of the device.
Before you start
Ensure the network connection is valid and correct, and the IP camera to add has already been activated. Please
refer to the User Manual for activating the inactive IP camera.
Step 1 Go to Menu > Camera > IP Camera.
Step 2 Select the IP camera from the list and
click to add the camera (with the
same admin password of the DVR’s).
Step 3 (Optional) Check Enable H.265 (For
Initial Access) for the connected IP
camera supporting H.265. Then the IP
camera will be encoded with H.265.
3.8 Connecting PoC Cameras
Purpose
Some models support PoC (Power over Coaxitron) cameras connection. DVR will detect the connected PoC
cameras automatically, manage the power consumption via the coaxial communication, and provide power to
the cameras via coaxitron.
Before you start
Connect the PoC camera to the DVR.
Step 1 Go to Menu > Camera > PoC Information.
Figure 3-8 PoC Information
Step 2 Check the status of connected PoC camera.
If the power consumption of
the DVR is lower than that of
AF camera, when AF or AT
camera is connected, there is
no video and “Insufficient
If the power consumption of the
DVR is higher than that of the AF
camera and lower than that of
the AT camera, when AF camera
is connected, it is powered on
If the power consumption of
the DVR is higher than that of
the AT camera, when AF or AT
camera is connected, it is
powered on normally.
