User Manual of Digital Video Recorder
107
Figure 6. 13 Smart Playback Interface
Playback progress bar: use the mouse to click any point of the progress bar or drag the progress bar to
locate special frames.
About video type bar: represents normal recording (manual or schedule); represents event
recording; represents smart search recording.
Table 6. 2 Detailed Explanation of Smart Playback
Button Operation Button Operation Button Operation
Smart search
Stop
/
Pause play/ Play
Process bar
/
Scaling
up/down the
time line
Video type / picture
6.1.6
Playing Back by System Logs
Purpose:
Play back record file(s) associated with channels after searching system logs.
Steps:
1.
Enter Log Information interface.
Menu>Maintenance>Log Information

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION DS-7324HGHI-SH and is the answer not in the manual?

HIKVISION DS-7324HGHI-SH Specifications

General IconGeneral
Voltage100 - 240 V
Product colorBlack
Audio input channels4.0 channels
Audio output channels1.0 channels
Video compression formatsH.264
RS-485 ports1
Video input channels24 channels
USB 2.0 ports quantity3
Ethernet LANYes
Ethernet interface typeGigabit Ethernet
Supported network protocolsTCP/IP, PPPoE, DHCP, Hik Cloud P2P, DNS, DDNS, NTP, SADP, SMTP, SNMP, NFS, iSCSI, UPnP, HTTPS
HDD interfaceSerial ATA, eSATA
Maximum HDD capacity6000 GB
Number of HDDs supported4
Power consumption (typical)55 W
Operating temperature (T-T)-10 - 55 °C
Operating relative humidity (H-H)10 - 90 %
Weight and Dimensions IconWeight and Dimensions
Weight5000 g
Dimensions (WxDxH)445 x 390 x 70 mm
