146
User Manual of Digital Video Recorder
1 self-adaptive 10M/100M network interface is provided for DS-7100, DS-7200HGHI series; 2 self-adaptive
10M/100M/1000M network interfaces for DS-8100/9000 series, and three working modes are configurable:
multi-address, load balance, network fault tolerance; and 1 self-adaptive 10M/100M/1000M network interface
for other models.
2.
Select the
General
tab.
3.
In the
General Settings
interface, you can configure the following settings: Working mode (applicable for
DS-8100/9000 only), NIC Type, IPv4 Address, IPv4 Gateway, MTU and DNS Server.
If the DHCP server is available, you can check the checkbox of
DHCP
to automatically obtain an IP
address and other network settings from that server.
The valid value of MTU is from 500 to 1500.
4.
After having configured the general settings, click the
Apply
button to save the settings.
Working Mode
There are two 10M/100M/1000M NIC cards provided by the DS-8100HGHI&HQHI-SH series devices, and it
allows the device to work in the Multi-address, Load Balance and Net-fault Tolerance modes.
Multi-address Mode:
The parameters of the two NIC cards can be configured independently. You can select
LAN1 or LAN2 in the NIC type field for parameter settings.
You can select one NIC card as default route. And then the system is connecting with the extranet the data will
be forwarded through the default route.
Net-fault Tolerance Mode:
The two NIC cards use the same IP address, and you can select the Main NIC to
LAN1 or LAN2. By this way, in case of one NIC card failure, the device will automatically enable the other
standby NIC card so as to ensure the normal running of the whole system.
Load Balance Mode:
By using the same IP address and two NIC cards share the load of the total bandwidth,
which enables the system to provide two Gigabit network capacity.
