User Manual of Digital Video Recorder
80
1)
Click
Edit
.
2)
In the message box, you can choose the day to which you want to set schedule.
3)
To schedule an all-day recording, check the checkbox after the
All Day
item.
Figure 5. 7 Edit Schedule- All Day
4)
To arrange other schedule, leave the
All Day
checkbox blank and set the Start/End time.
Figure 5. 8 Edit Schedule- Set Time Period
Up to 8 periods can be configured for each day. And the time periods cannot be overlapped with each other.
Repeat the above steps 1)-4) to schedule recording for other days in the week. If the schedule can also be
set to other days, click
Copy
.
Figure 5. 9 Copy Schedule to Other Days
The
Holiday
option is available when you enable holiday schedule in
Holiday settings
. See C
hapter 5.7
Configuring Holiday Record.
5)
Click
OK
to save setting and back to upper level menu.
