HIKVISION DS-7332HGHI-SH User Manual

User Manual of Digital Video Recorder
117
 Here we take the backup by motion detection as the example.
 Backup by alarm input is not supported by DS-7100 and DS-7200HGHI series DVR.
 Backup by VCA (Line Crossing Detection, Intrusion Detection) search is not supported by DS-7100.
2) Check the checkbox of cameras and set the search time.
3) Click Search button to enter the Search Result interface.
Figure 7. 8 Event Search for Backup
3. Select record files to export.
1) Select an alarm input in the list and click Quick Export button to enter Export interface.
2) Clicking Details button will take you to the interface with detailed information of all channels
triggered by the event.
Figure 7. 9 Result of Event Search
3) Click Details button to view detailed information of the record file, e.g. start time, end time, file size,
etc.
The size of the currently selected files is displayed in the lower-right corner of the window.

HIKVISION DS-7332HGHI-SH Specifications

General

HDD capacity	18000 GB
HDD interface	Serial ATA
Number of HDDs supported	4
Product color	Black
Channels quantity	32 channels
Maximum frame rate	30 fps
Video compression formats	H.264
Playback resolutions supported	1920x1080, 1280x1024, 1280x720, 1024x768, 704x576, 704x480
BNC input ports	32
USB 2.0 ports quantity	3
Ethernet interface type	Gigabit Ethernet
Supported network protocols	TCP/IP, PPPoE, DHCP, EZVIZ Cloud P2P, DNS, DDNS, NTP, SADP, SMTP, SNMP, NFS, iSCSI, UPnP, HTTPS
Power requirements	100-240V AC, 47 - 63Hz
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Dimensions (WxDxH)	445 x 390 x 70 mm
