User Manual of Digital Video Recorder
47
main output.
You can select the Menu Output Mode under Menu>Configuration>More Settings to Auto, or HDMI (1)/VGA
and then restart the device to switch the main output back to HDMI (1)/VGA output.
3.2.4 Quick Setting Toolbar in Live View Mode
On the screen of each channel, there is a quick setting toolbar which shows when you point the mouse to the
bottom of the screen.
Figure 3. 3 Quick Setting Toolbar
Table 3. 6 Description of Quick Setting Toolbar Icons
Enable/Disable
Manual Record
The DS-7100-SH series DVR does not support the RS-485 interface, thus the PTZ control function is not
applicable to it.
Instant Playback only shows the record in last five minutes. If no record is found, it means there is no
record during the last five minutes.
Digital Zoom can zoom in the selected area to the full screen. Click and draw to select the area to zoom in,
as shown in Figure 3. 4.
