HIKVISION DS-9616NI-I8 Quick Start Guide

1 1 S E T U P R E C O R D I N G ( c o n t i n u e d )
 Record Quality
• Main Stream
1. Go to RECORDING CONFIGURATION > RECORD QUALITY > MAIN STREAM and set
the following items:
- Stream Type enables/disables audio streaming from the cameras (if the camera does
not have audio capabilities, Stream Type will have only Video option).
- Resolution sets recording resolution.
- Bitrate Type saves HDD space when set to Variable. Choices: Variable and
Constant.
- Video Quality adjusts picture clarity (high setting = four green squares is default).
Consider highest if hard drive space allows. Medium setting is a balance between good
picture and saving HDD space.
- Frame Rate sets recording frame rate (8 fps on continuous and 15 on motion by
default). Higher frame rates require more storage, but allows better slow motion
playback.
- Max Bitrate Mode chooses between pre-set bitrate values and customized values
(General setting is default).
IP Cameras
- Max Bitrate (kbps) is the chosen bitrate for streaming the video. Max Bitrate should be
adjusted to meet or exceed the rate recommended by the system for the chosen
parameters.
- Max Bitrate Recommended is impacted by resolution, quality, and framerate.
- Record Audio turns on audio recording. Requires connection of external microphone
or camera with built in mic.
- Video Stream determines which stream is recorded. Leave at default (Main Stream).

MAIN
STREAM
Select tab
 CAMERA
Select IP camera
 EVENT
For event recording only (motion
or alarm)
CONTINUOUS
For live view image and
continuous recording
VIDEO QUALITY
Selectnumber of green squares
to set quality (in example,
sensitivity is set to 3)






HIKVISION DS-9616NI-I8 Specifications

General

Sequence mode	Yes
Internal memory	4096 MB
Number of users	128 user(s)
Maximum resolution	3840 x 2160 pixels
Alarm input channels	16
Internal memory type	DDR4
Throughput data rate	256 Mbit/s
Video input channels	16 channels
Alarm output channels	4
Supported resolutions	3840 x 2160, 2560 x 1440, 1920 x 1080, 1600 x1200, 1280 x 1024, 1280 x 720, 1024 x 768
Video formats supported	H.264, H.264+, H.265, MPEG4
Analog signal format system	NTSC, PAL
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
RAID levels	0, 1, 5, 10
HDD capacity	8000 GB
HDD interface	Serial ATA
Maximum storage capacity	- TB
Number of HDDs installed	-
Number of HDDs supported	8
Total installed storage capacity	16000 GB
Product color	Black
Rack capacity	2U
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	200 W

Weight and Dimensions

Depth	470 mm
Width	445 mm
Height	90 mm
