HIKVISION DS-K2602 - DS-K2604 Terminal Description

DS-K2600 Series Access Controller
14
No.
DS-K2602
B8
D1-
B9
E-Lock2
D2+
Door 2 Door Relay Input (Dry Contact)
B10
D2-
B11
Door
Magnetics
Detector
S1
Door 1 Magnetic Detector Input
B12
GND
Signal Grounding
B13
S2
Door 2 Magnetic Detector Input
B14
Door
Button
B1
Door 1 Door Button Input
B15
GND
Signal Grounding
B16
B2
Door 2 Door Button Input
C1
Power
+12V
DC12V Cathode
C2
GND
Grounding
C3
Battery
BAT+
DC12V Battery Cathode
C4
BAT-
DC12V Battery Anode
C5
Card Reader
485
Interface
RS
485A+
Card Reader RS485+ Access
C6
RS 485A-
Card Reader RS485- Access
C7
GND
Grounding
C8
RS
485B+
Card Reader RS485+
C9
RS 485B-
Card Reader RS485-
C10
GND
Grounding
C11
RS-485
Interface
RS
485C+
Uplink RS485+Communication
C12
RS 485C-
Uplink RS485-Communication
