Appendix A DIP Switch
Description
There are two groups of DIP switches on the master lane control board. Take the 8-bit DIP
switch as an example; No.1 to No 8 is from the low bit to the high bit.
When the switch is towards ON, it means the switch is enabled, otherwise, the switch is off.
If you set the DIP switch like the figure displayed below, its binary value is 00001100, and its
decimal value is 12.
