HIKVISION DS-K3G200X-R/M-Dm55 - Sub Optional Board Terminal Description (Optional); Card Reader Board Terminal Description

Figure 4-4 Main Oponal Board Terminal
4.4.4 Sub
Oponal Board Terminal Descripon (Oponal)
Figure 4-5 Sub Oponal Board Terminal
Note
●
RS-485B corresponds to port 6 on web and is for QR code scanner connecon by default.
●
RS-485D corresponds to port 4 on web and is for card reader connecon by default.
●
RS-232B corresponds to port 2 on web and is for ngerprint reader connecon by default.
4.4.5 Card Reader Board Terminal Descripon
The card reader board can be connected to the access control board via RS-485 interface.
