Face Recognition Terminal·Quick Start Guide
13
Chapter 6 Basic Operation
Purpose:
After entering the administrative backend, you can manage users, set communication parameters,
change device password, manage and maintain data, and view device information.
6.1 Enter Administrative Backend
Purpose:
You should enter the de administrative backend before setting other parameters.
Steps:
1. On the initial page, long tap the screen for 3s to enter the input password page.
2. Input the password in the text box. The password here refers to the activation password.
3. Tap OK to enter the backend.
4. (Optional) Tap Exit at the lower left corner to exit the backend.
6.2 Communication Settings
Purpose:
You can set the device network parameters and COM parameters.
6.2.1 Setting Network Parameters
Purpose:
The device contains two network interfaces. You can select to enable one of them or both of them,
and set the network parameters, including IP address, gateway, and subnet mask. The device can
use the network interface to communicate with iVMS-4200 control client.
Steps:
1. In the backend, tap to enter the Communication Settings page.
2. Tap Network to enter the Network tab.
3. Set the network interface parameters, including IP address, subnet mask, and gateway.
Notes:
The device IP address and the PC’s IP address should be in the same LAN.
If using both of the network interfaces at the same time, the IP addresses of network
interface 1 and 2 should be different to avoid IP address confliction.
4. Tap Logout to exit the page and save the parameters.
6.2.2 Setting COM Parameters
Purpose:
The device can be connected to other access control device via the COM interface. After selecting
