Video Intercom Demo Case·User Manual
12
4 Live View
For network indoor stations, you can get the live view of the added door stations on the
live view page of the indoor station.
Before you start:
 Make sure both the door station and the indoor stations are well-connected.
 Make sure the door station and the indoor stations have been activated.
Steps:
1. Add the same door station to the 2 indoor stations.
1) Tap Settings -> -> Configuration, and input the configuration password to
enter the configuration page.
The default configuration password is 888999.
2) Tap to enter the device management page.
3) Tap Main Door Station, select the main door station type as Main Door Station,
and input the IP of the door station.
The default IP of the door station in the demo case is 192.0.0.70.
2. On the home page, and tap Live View tab to enter the live view page.
Figure 4-1 Live View Page
3. Tap -> Main Door Station to get the live view of the door station.

HIKVISION DS-KH6320-WTE1 Specifications

General

Display Size	7 inch
Resolution	1024 × 600
Network Protocols	TCP/IP, SIP, RTSP
Audio Input	Built-in omnidirectional microphone
Audio Output	Built-in loudspeaker
Power Consumption	≤ 6 W
Operation Method	Touchscreen
Audio Compression Standard	G.711 U
Audio Compression Rate	64 Kbps
Wi-Fi Standard	IEEE802.11 b/g/n
Wi-Fi Frequency Range	2.4 GHz
RS-485	1
Working Temperature	-10 °C to 55 °C (14 °F to 131 °F)
Audio	Two-way audio
Power Supply	12 VDC, PoE (IEEE802.3af)
Installation	Wall-mounted
Display Type	TFT LCD
Network Interface	10/100 Mbps Ethernet
Alarm Output	1 channel
TF Card	up to 32 GB
Working Humidity	10% to 90%
