HIKVISION DS-KH6320-WTE1 User Manual

2 Local Operaon
2.1 Call Sengs
2.1.1 Add Contact
Steps
1.
Tap Call → to enter the contact list page.
Figure 2-1 Contact List
2.
Tap to pop up the contact adding dialog.
3. Enter the contact name and the room No.
4. Tap OK to save the
sengs.
Note
Up to 200 contacts can be added.
2.1.2 Call Resident
Network Indoor Staon Operaon Guide
2

HIKVISION DS-KH6320-WTE1 Specifications

General

Display Size	7 inch
Resolution	1024 × 600
Network Protocols	TCP/IP, SIP, RTSP
Audio Input	Built-in omnidirectional microphone
Audio Output	Built-in loudspeaker
Power Consumption	≤ 6 W
Operation Method	Touchscreen
Audio Compression Standard	G.711 U
Audio Compression Rate	64 Kbps
Wi-Fi Standard	IEEE802.11 b/g/n
Wi-Fi Frequency Range	2.4 GHz
RS-485	1
Working Temperature	-10 °C to 55 °C (14 °F to 131 °F)
Audio	Two-way audio
Power Supply	12 VDC, PoE (IEEE802.3af)
Installation	Wall-mounted
Display Type	TFT LCD
Network Interface	10/100 Mbps Ethernet
Alarm Output	1 channel
TF Card	up to 32 GB
Working Humidity	10% to 90%
