The indoor staon and indoor extension can receive calls from the door staon, the
main staon or iVMS-4200 Client.
On the call from door staon interface, there are 2 unlock buons: Unlock 1, and
Unlock 2. When you tap Unlock 1, the building gate will open by default, and when
you tap Unlock 2, the door connected to the door staon with the secure control
door unit will open.
Tap the capture
buon to capture the live view picture when speaking with the door
staon. And prompts "Captured" will display on the screen.
Indoor extension can receive calls from the door staon and the main staon only.
2.1.5 View Call Logs
Steps
1.
Tap Call → to enter the call log page.
Figure 2-3 Call Logs
2. Tap a piece of call logs in the list to call back.
Note
●
Indoor extension does not support this funcon.
●
The indoor staon saves call logs from door staon, outer door staon,
management center and other indoor staons.
●
Hold a piece of call logs to open the call logs handling menu. Tap Delete to
delete the piece of call logs. Tap Clear to delete all pieces of call logs.
Network Indoor Staon Operaon Guide
4

HIKVISION DS-KH6320-WTE1 Specifications

General

Display Size	7 inch
Resolution	1024 × 600
Network Protocols	TCP/IP, SIP, RTSP
Audio Input	Built-in omnidirectional microphone
Audio Output	Built-in loudspeaker
Power Consumption	≤ 6 W
Operation Method	Touchscreen
Audio Compression Standard	G.711 U
Audio Compression Rate	64 Kbps
Wi-Fi Standard	IEEE802.11 b/g/n
Wi-Fi Frequency Range	2.4 GHz
RS-485	1
Working Temperature	-10 °C to 55 °C (14 °F to 131 °F)
Audio	Two-way audio
Power Supply	12 VDC, PoE (IEEE802.3af)
Installation	Wall-mounted
Display Type	TFT LCD
Network Interface	10/100 Mbps Ethernet
Alarm Output	1 channel
TF Card	up to 32 GB
Working Humidity	10% to 90%
