HIKVISION DS-KH8301-WT User Manual

Video Intercom Indoor Station·User Manual
49
 For indoor station, the linkage between indoor station and master station can be
realized after adding master station IP Address,
 For indoor station, the video intercom among indoor stations of same building can be
realized after adding the door station IP Address,
 For indoor station, after adding SIP Server Address IP, the video intercom of same
community: video intercom between indoor stations of different building, calling
indoor station from outer door station and video intercom between management
center and indoors.
 For indoor station, alarm messages can be automatically uploaded to the
management center after adding the security control panel.
 For indoor station, after adding the main indoor station, it can view the live view of
door station or IP camera added by the main indoor station, and the communication
between the main door station and indoor extension can be realized.

HIKVISION DS-KH8301-WT Specifications

General

Color	Yes
Video codecs	H.264
Certification	FCC, IC, CE, C-TICK, ROHS, REACH, WEEE
Connectivity technology	Wired
Sustainability certificates	RoHS
Voice codecs	G.711u
Display diagonal	7 \
Touchscreen type	Capacitive
Display resolution	1024 x 600 pixels
Display technology	LCD/TFT
Proper use	Indoor
Control type	Touch
Product color	White
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Ethernet LAN (RJ-45) ports	1
Supported network protocols	TCP/IP, RTSP
Outdoor unit included	No
Operating system installed	Linux
Operating relative humidity (H-H)	10 - 90 %
Main monitor station operating temperature (T-T)	-10 - 55 °C
Indoor unit power type	AC/DC
Power consumption (typical)	10 W
Megapixel	0.3 MP
Sensor type	CMOS
Maximum frame rate	30 fps
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB

Weight and Dimensions

Depth	26 mm
Width	217 mm
Height	142 mm
