 You must create a password to activate the indoor station for your first time usage
and when it is not activated.
 Only after activating the indoor station, you can operation it locally and remotely.
 Here the activation interface of models DS-KH8301-WT/DS-KH8300-T indoor stations
is taken as example.
10.2 User Interface Description
10.2.1 User Interface of Indoor Station
Figure 9-2 User Interface of Indoor Station (Page 1)
Figure 9-3 User Interface of Indoor Station (Page 2)
 Slide left and right to realize the switch between two interface pages (except for
DS-KH6210(L)).
 Here the user interface of DS-KH8501-WT is taken as as example.

HIKVISION DS-KH8301-WT Specifications

General

Color	Yes
Video codecs	H.264
Certification	FCC, IC, CE, C-TICK, ROHS, REACH, WEEE
Connectivity technology	Wired
Sustainability certificates	RoHS
Voice codecs	G.711u
Display diagonal	7 \
Touchscreen type	Capacitive
Display resolution	1024 x 600 pixels
Display technology	LCD/TFT
Proper use	Indoor
Control type	Touch
Product color	White
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Ethernet LAN (RJ-45) ports	1
Supported network protocols	TCP/IP, RTSP
Outdoor unit included	No
Operating system installed	Linux
Operating relative humidity (H-H)	10 - 90 %
Main monitor station operating temperature (T-T)	-10 - 55 °C
Indoor unit power type	AC/DC
Power consumption (typical)	10 W
Megapixel	0.3 MP
Sensor type	CMOS
Maximum frame rate	30 fps
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB

Weight and Dimensions

Depth	26 mm
Width	217 mm
Height	142 mm
