Video Intercom Villa Door Station User Manual
29
5. Select Cropping Resolution.
6. Click Save.
5.5.6 Event Settings
Motion Detection
Motion detection detects the moving objects in the configured security area, and a series of actions
can be taken when the alarm is triggered.
Steps
1. Click Event → Motion to enter the settings page.
Figure 5-13 Motion Detection
2. Check Enable Motion Detection to enable the function.

Table of Contents

Other manuals for HIKVISION DS-KIS603-P

Preview: Configuration Guide
Configuration Guide47 pages

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION DS-KIS603-P and is the answer not in the manual?

HIKVISION DS-KIS603-P Specifications

General IconGeneral
ModelDS-KIS603-P
CategoryIntercom System
Resolution1024 x 600
Camera2 MP HD Camera
Audio InputBuilt-in Omnidirectional Microphone
Audio OutputBuilt-in Loudspeaker
Operating Temperature-10°C to 55°C (14°F to 131°F)
Supported ProtocolsTCP/IP, SIP, RTSP
Display7-inch TFT LCD
Network ProtocolTCP/IP
Power Supply12 VDC
InstallationSurface Mount
IR SupplementIR Supplement
Protection LevelIP65
Power Consumption<10 W
Humidity10% - 90% (non-condensing)
Communication InterfaceEthernet
