Video Intercom Villa Door Station User Manual
33
Figure 5-15 Device ID Settings
2. Select the device type from the drop-down list, and set the corresponding information.
3. Click Save to enable the device number configuration.
Note
● For main door station (D series or V series), the serial No. is 0.
● For sub door station (D series or V series), the serial No. cannot be 0. Serial No. ranges from 1
to 99.
● For each villa or building, at least one main door station (D series or V series) should be
configured, and one sub door stations (D series or V series) can be customized.
● For one main door station (D series or V series), up to 8 sub door stations can be configured.
Linked Network Settings
Steps
1. Go to Intercom → Session Settings to enter the settings page.
2. Set Register Number and Registration Password.
3. Set Main Station IP and VideoIntercom Server IP.
4. Enable Protocol 1.0.
5. Click Save to enable the settings.
Time Parameters
Go to Intercom → Time Parameters to enter the page.
Configure Max. Call Duration, Max. Message Duration, Max. Ring Duration, and click Save.

HIKVISION DS-KV6113-PE1 Specifications

General

Color	-
Wall mountable	Yes
Connectivity technology	Wired
Megapixel	2 MP
Supported video modes	720p, 1080p
Viewing angle, vertical	75 °
Maximum video resolution	1920 x 1080 pixels
Viewing angle, horizontal	129 °
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, RTSP
Product color	Black, Grey
International Protection (IP) code	IP65
LED type	IR
Indoor unit included	No
Outdoor unit power type	DC
Power consumption (typical)	10 W
Operating temperature (T-T)	-40 - 55 °C
Operating relative humidity (H-H)	10 - 95 %
Display diagonal	- \
Operating system installed	Embedded LINUX

Weight and Dimensions

Depth	65 mm
Width	138 mm
Height	27 mm
