E Series Network Speed Dome·Quick Guide
23
2). Insert the bolts into the 3 screw holes on the dome.
3). Rotate the bolts through the 3 screw holes.
4). Reinstall the toggles as shown in Figure 2-23.
Toggle
Bolt
Figure 2-23 Install Toggle Bolts
4. Align the toggle bolts with the screw holes on the ceiling.
5. Push the dome to the mounting hole on the ceiling.
Figure 2-24 Push to the Mounting Hole
6. Rotate the bolts again. The toggle will automatically rotate down to secure the dome to the
ceiling.
