HIKVISION E Series Quick Guide

E Series Network Speed Dome·Quick Guide
28
Lens Cover
Sticker
Foam
Figure 2-33 Dissemble the Speed Dome
5. Align the ceiling mount with the screw holes on the drill template. Secure the ceiling mount to
the ceiling with screws(supplied) as follows.
Hook
Ceiling
Mount
Figure 2-34 Install Ceiling Mount
6. Align the hook of the ceiling with unlock label on the speed dome.
7. Push the speed dome to the ceiling mount and rotate clockwise to secure it.
