HIKVISION HiLook NVR-108MH-D User Manual

Network Video Recorder User Manual
41
● Load Balance Mode:
● By using the same IP address and two NIC cards share the load of the total bandwidth,
which enables the system to provide two Gigabit network capacity
Note
Working mode is only available for certain models.
NIC Type
Select NIC type as your desire.
DHCP
If the DHCP server is available, you can check Enable DHCP to automatically obtain an IP
address and other network settings from that server.
MTU
The maximum transmission unit (MTU) is the size of the largest network layer protocol data
unit that can be communicated in a single network transaction.
Obtain DNS Automatically
If DHCP is checked. You can check Obtain DNS Automatically to obtain Preferred DNS
Server and Alternate DNS Server.
3. Click Apply.
6.2.2 DDNS
Dynamic domain name server (DDNS) maps dynamic user IP addresses to a fixed domain name
server.
Before You Start
Register DynDNS, PeanutHull and NO-IP services with your ISP.
Steps
1. Go to Configuration → Network → General → DDNS.

HIKVISION HiLook NVR-108MH-D Specifications

General

Model	NVR-108MH-D
Video Input	8-ch
IP Video Input	8-ch
Incoming Bandwidth	80 Mbps
Outgoing Bandwidth	80 Mbps
Video Output	1-ch
Synchronous Playback	8-ch
HDD Bays	1
SATA	1 SATA interface
Capacity	6 TB
USB Interface	2 × USB 2.0
Power Supply	12 VDC
Consumption (without HDD)	≤ 10 W
Operating Humidity	10% to 90%
Recording Resolution	8 MP/6 MP/5 MP/4 MP/3 MP/1080p/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Max HDD Capacity	Up to 6 TB capacity
Network Interface	1 RJ-45 10/100 Mbps self-adaptive Ethernet interface
Operating Temperature	-10 °C to +55 °C
Weight (without HDD)	≤ 1 kg
Weight	≤ 1 kg
HDMI Output	1-ch, 4K (3840 × 2160)/30Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
VGA Output	1-ch (1920x1080/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz)
