Network Video Recorder User Manual
80
Chapter 8 Alarm
When events occur, you can view their details in alarm center.
8.1 Set Event Hint
Select the events to hint in alarm center.
Steps
1. Click at the upper-right corner.
2. Set Exception, Basic Event, or Smart Event as your desire.
Figure 8-1 Alarm Center
3. Click and select events to hint.
4. Click OK.
When the selected events occur, the alarm information will be displayed in (locating at the
upper-right corner of local menu).
8.2 View Alarm in Alarm Center
Steps
1. Click at the upper-right corner of local menu.
2. Click Exception, Basic Event, or Smart Event to view as your desire.

HIKVISION HiLook NVR-108MH-D Specifications

General

Model	NVR-108MH-D
Video Input	8-ch
IP Video Input	8-ch
Incoming Bandwidth	80 Mbps
Outgoing Bandwidth	80 Mbps
Video Output	1-ch
Synchronous Playback	8-ch
HDD Bays	1
SATA	1 SATA interface
Capacity	6 TB
USB Interface	2 × USB 2.0
Power Supply	12 VDC
Consumption (without HDD)	≤ 10 W
Operating Humidity	10% to 90%
Recording Resolution	8 MP/6 MP/5 MP/4 MP/3 MP/1080p/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Max HDD Capacity	Up to 6 TB capacity
Network Interface	1 RJ-45 10/100 Mbps self-adaptive Ethernet interface
Operating Temperature	-10 °C to +55 °C
Weight (without HDD)	≤ 1 kg
Weight	≤ 1 kg
HDMI Output	1-ch, 4K (3840 × 2160)/30Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
VGA Output	1-ch (1920x1080/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz)
