HIKVISION HWI-D720H-V/-Z

Network Dome Camera·Quick Start Guide
20
1. Loosen the pan adjusting screw to adjust the pan angle from 0° to
355° and tilt angle from 0° to 75°.
2. Fasten the adjusting screw.
Pan: 0° to 355°
Tilt: 0° to 75°
Angle Adjustment
2.3.2 Zoom and Focus Adjustment
Manually Adjustment
Certain camera models of this series have the lens that zoom and
focus levels must be manually adjusted via zoom/focus lever and you
can use zoom lever and focus lever to adjust the lens.
Steps:
1. Loosen the zoom lever and move the lever between T (Tele) and
W (Wide) to obtain the appropriate angle of view.
