HIKVISION HWI-D720H-V/-Z

Network Dome Camera·Quick Start Guide
22
2.4 Installation of Network Cable Waterproof
Jacket (Optional)
Purpose:
If the camera is installed outdoor, you can adopt the waterproof
accessory for the network cable after the camera is secured on the
installation surface.
①
②
③
④
⑤
⑥ ⑦
Figure 2-15 Waterproof Accessory Components
Table 2-1 Components
No.
Components
1
Network Interface Socket
2
O-Type Gasket
3
Network Plug
4
Waterproof Endcap
5
Waterproof Rubber Gasket
6
Lock Nut
7
Network Cable from Router/Switch
