HIKVISION N4225IH-DE User Manual

Digital Video Recorder User Manual
118
Step 6 Set detection area and sensitivity. Refer to step 3 of Chapter 8.1 Setting Motion Detection.
Step 7 Click to set motion detection alarm response actions. Refer to step 4 of Chapter 8.1
Setting Motion Detection.
Step 8 Click Apply to save the settings.
This function is only applicable to Hikvision PIR analog cameras.
The PIR alarm does not support detection area configuration. It is full screen by default.
The PIR alarm does not support sensitivity configuration.
If you disable false alarm filter, only when the motion detection events are triggered, the
motion detection alarm will be triggered. The PIR alarm will not be considered.
8.3 Setting Sensor Alarms
Purpose
Set up handling method of an external sensor alarm.
Step 9 Go to Menu > Configuration > Alarm > Alarm Input.
Figure 8-7 Alarm Input Settings Interface
Step 10 Set the handling method of the selected alarm input.
Check the Enable checkbox and click button to set its alarm response actions.

HIKVISION N4225IH-DE Specifications

General

Model	N4225IH-DE
Category	Security Camera
IR Range	Up to 30m
WDR	120dB
Video Compression	H.265+/H.265/H.264+/H.264
Ingress Protection	IP67
Image Sensor	1/2.8" Progressive Scan CMOS
Lens	2.8 mm
Power Supply	12 VDC ± 25%
Operating Conditions	-30 °C to 60 °C (-22 °F to 140 °F), humidity: ≤ 95%, non-condensing
Network Interface	RJ45 10M/100M Ethernet
Day/Night	ICR
