HIKVISION Network Dome Camera User Manual

Installation Manual of Network Dome Camera
17
Protection, Watermark
Interface
Audio Input 1 channel microphone input, 3.5mm mini-jack
Audio Output 1 channel 3.5mm audio interface (Line level, 600Ω)
Communication
Interface
1 RJ45 10M / 100M self-adaptive Ethernet interface, 1 RS-485 interface
Alarm Input 2 channel
Alarm Output 2 channel
Video Output 1Vp-p Composite Output (75Ω/RCA)
General
Operating
Condition
-10 ~60 (14°F~140°F), Humidity 90% or less(non℃℃ -condensing)
Power Supply DC12V±10% / PoE (AC24V optional)
Power
Consumption
4.5W MAX
-I: 6W MAX(6.5W MAX with ICR working)
Impact Protection IEC60068-2-75Eh,50J;EN50102, up to IK10
IR Range -I: Within 10-20 meters (32.8-65.6ft)
Dimensions(mm) φ140 × 114 (φ5.5" × 4.9")
Weight
1400g (3.08lbs)
*”I” series supports 10-20 meters (32.8-65.6ft) IR Range
Dimensions
Hangzhou Hikvision Digital Technology Co., Ltd. | Copyright ©

HIKVISION Network Dome Camera Specifications

General

Lens	Varies by model (e.g., 2.8mm, 4mm, 6mm fixed lens; varifocal lens options available)
IR Range	Up to 30m (varies by model)
Video Compression	H.265+/H.265/H.264+/H.264
Power Supply	PoE (802.3af)
Operating Conditions	-30°C to 60°C (-22°F to 140°F)
Wide Dynamic Range (WDR)	120 dB
Ingress Protection	IP67
Vandal Resistance	IK10
Network Interface	RJ45 10/100Mbps Ethernet
Humidity	95% or less (non-condensing)
