3.3 Transfer Plate Number via Wiegand Interface
3.3.1 Overview
Transfer the plate number via Wiegand interface, which is the private protocol.
3.3.2 Advantage
Compatible directly with PAXTON access control system (managed by NET2 platform).
3.3.3 Applicable Wiegand Protocol
26-bit Wiegand Protocol
3.3.4 Plate Number Encoding Mode
Figure 3-8 Wiegand Protocol Flow Chart
Example
Plate No.: 2180870
The 24 bit encoded by SHA1 mode is 0x54 0x52 0x22
Add parity bit based on 3.1.6 Use Wiegand Protocol to Transfer Card
No
Add parity bit to 26 bit both before and after the number based on 26
bit protocol
3.3.5 Configure Parameters
Set the Wiegand Type as Paxton.
Steps:
1. Go to >Network->Basic setting->Wiegand.
2. Select Wiegand Type as Paxton 26bit.
3. Click Save.
