4.18 Siderail Retraction Assembly
Chapter 4: Removal, Replacement, and Adjustment Procedures
4
Hill-Rom® Basic Care™ Bed, Hill-Rom® 305 Manual Bed, Page 4 - 43
Hill-Rom® 405 Electric Bed Service Manual (MAN336 REV 2)
Wear eye protection. Failure to do so may cause eye injury.
4. Put on eye protection.
5. Remove the two screws (D) that attach the top cane (E) to the siderail (A).
6. Remove the two spring assemblies (F) from the siderail (A).
Replacement
1. Do the removal procedure in the reverse order.
There are both left-hand and right-hand siderail retraction assemblies.
2. Do the “Function Checks” on page 2-2.
