22
Operations
Cleaning Procedure - continued
4. Start at wall closest to power outlet. For large areas
flip handle and operate machine in parallel passes,
overlapping brush path. Clean perimeter last.
5. During operation, observe the following: The EX12
is equipped with clear internal covers to facilitate
operator viewing of dirty solution and vacuum air
flow.
During operation, observe the vacuum intake
cover. Large amounts of water or foam entering the
vacuum system can damage the vacuum motor.
NOTE: If you notice either condition, shut down the
machine immediately.
Empty recovery tank and/or add de-foamer to
recovery tank.
6. Use right side of machine for cleaning against
walls.
7. After cleaning, turn off all controls, return brush to
storage position and carefully unplug machine.
HIL56086 - Operators Manual - Trident EX12
