English 11
Status Meaning
The service indicator lights red. • End of service interval – servicing is due. After
the LED lights for the first time, the diamond
cutter can continue to be used for several hours
(running time) before the automatic cut-out is
activated.
• Return the product to Hilti Service for servicing
in good time in order to ensure that it is always
ready for use.
The service indicator blinks red. • The product is defective. Have the product
repaired by Hilti Service.
3.9 Depth gauge
The depth gauge is not one of the items supplied with the DCH 300 diamond cutter, but it is available
as a retrofit (accessory).
The desired maximum cutting depth can be set with the aid of the cutting depth scale on the depth gauge.
The depth gauge also improves dust removal performance.
3.10 Items supplied
Diamond cutter with hood, depth gauge (only DCH 300X), Ø 41 mm clamping flange, M14 clamping nut,
24 / 10 mm AF wrench, 6 mm AF hex key, Operating instructions.
Other system products approved for use with this product can be found at your local Hilti Store or online at:
www.hilti.group | USA: www.hilti.com
4 Technical data
4.1 Technical data
For rated voltage, rated current, frequency and/or input power, refer to the country-specific type
identification plate.
If the tool is powered by a generator or transformer, the generator or transformer’s power output must be
at least twice the rated input power shown on the rating plate of the tool. The operating voltage of the
transformer or generator must always be within +5% and -15% of the rated voltage of the tool.
DCH 300 DCH 300–X
Weight in accordance with EPTA procedure 01
9.4 kg 9.4 kg
Arbor thread size
M16 × 1.5 M16 × 1.5
Cutting disc mounting flange
22.2 mm 22.2 mm
Cutting disc diameter
305 mm 305 mm
Cutting disc thickness
≤ 3.5 mm ≤ 3.5 mm
Rated speed
4,900 /min 4,900 /min
Clamping nut tightening torque (for securing the
cutting disc)
40 Nm …50 Nm 40 Nm …50 Nm
4.2 Noise information and vibration values determined in accordance with EN 60745
The sound pressure and vibration values given in these instructions have been measured in accordance with
a standardized test and may be used to compare one power tool with another.
The data given represents the main applications of the electric tool. However, if the electric tool is used for
different applications, with different accessory tools, or is poorly maintained, the data may vary. This may
significantly increase exposure over the total working period.
An accurate estimation of exposure should also take into account the times when the power tool is switched
off, or when it is running but not actually being used for a job. This may significantly reduce exposure over
the total working period.
Printed: 02.02.2018 | Doc-Nr: PUB / 5398464 / 000 / 00
