22 English
3.3 Items supplied
Laser range meter, wrist strap, soft pouch, short measuring extension, AC
adapter with micro-USB cable.
You can find other system products approved for your product at your local
Hilti Center or online at: www.hilti.com.
4 Technical data
4.1 Distance measurement
Note
Distance and inclination measurement accuracy: Influences such as
high temperature fluctuations, dampness, shock, dropping, etc. can
affect the accuracy of the tool. Unless stated otherwise, the tool was
adjusted or calibrated under standard ambient conditions (MIL-STD-
810G). As a basic principle, when taking distance measurements an
additional distance-dependent error of 0.02 mm per meter is to be
taken into account. The reference for inclination measurements is the
underside of the tool.
PD-C PD-CS
Operating modes
• Single mea-
surements
• Range (multi-
ple) measure-
ments
• Single mea-
surements
• Range (multi-
ple) measure-
ments
Distance measurement accuracy
(2σ, standard deviation)
±1.0 mm ±1.0 mm
Inclination measurement accu-
racy (2σ, standard deviation)
±0.3° ±0.3°
Beam divergence
0.20 mrad …
0.45 mrad
0.20 mrad …
0.45 mrad
Measuring range with target plate
0 m … 200 m
(0 ft … 656 ft)
0 m … 200 m
(0 ft … 656 ft)
Minimum distance for aiming with
the laser point and cross hairs
without use of the zoom function
> 2 m
(> 6 ft - 10 in)
> 2 m
(> 6 ft - 10 in)
Minimum distance for aiming with
the laser point and cross hairs at
the maximum zoom setting
> 5 m
(> 16 ft)
> 5 m
(> 16 ft)
