Hilti PR 2-HS A12 User Manual

4 English 2131237
*2131237*
▶ Do not disassemble, squash or incinerate batteries and do not subject them to temperatures over
80°C (176°F). This presents a risk of fire, explosion or injury through contact with caustic substances.
▶ Do not subject the battery to hard mechanical impacts and do not throw the battery.
▶ Batteries must be kept out of reach of children.
▶ Avoid ingress of moisture. Ingress of moisture may cause a short circuit, resulting in burning injuries or
fire.
▶ Under abusive conditions, liquid may leak from the battery. Avoid contact with the liquid. If contact
accidentally occurs, flush with water. If the liquid contacts the eyes, also seek medical attention.
Liquid leaking from the battery may cause irritation or burns.
▶ Use only batteries of the type approved for use with the applicable tool. Use of other batteries or
use of the batteries for purposes for which they are not intended presents a risk of fire and explosion.
▶ Store the battery in a cool and dry place. Never store the battery where it is exposed to direct sunlight or
sources of heat, e.g. on heaters / radiators or behind glass.
▶ When not in use, keep the battery and the charger away from paper clips, coins, keys, nails,
screws or other small metal objects that could cause a short circuit at the battery terminals or the
charging contacts. Short-circuiting the contacts on a battery or charger may cause burning injuries or
start a fire.
▶ Do not charge or continue to use damaged batteries (e.g. batteries with cracks, broken parts, bent
or pushed-in and/or pulled-out contacts).
▶ Recharge only with the charger specified by the manufacturer. A charger that is suitable for a certain
type of battery may present a risk of fire when used with other types of battery.
▶ Observe the special guidelines applicable to the transport, storage and use of Li-ion batteries.
▶ The battery must be insulated or removed from the tool before the tool is shipped or sent by mail.
Leaking batteries may damage the tool.
▶ If the battery gets noticeably hot when not in use, this may indicate that the battery or the tool / battery
system is faulty. In this case, place the tool in a non-flammable location, well away from flammable
materials, where it can be kept under observation and allowed to cool down.
3 Description
3.1 Overview of the product
3.1.1 PR 2-HS A12 rotating laser 1
@
Laser beam (plane of rotation)
;
Rotary head
=
Grip
%
Battery release button
&
Liion battery
(
Battery charge status display
)
Control panel
+
Base plate with 5/8" thread
3.1.2 PR 2-HS A12 control panel 2
@
On/off button
;
LED: Auto-leveling
=
Button and LED: Shock warning deactiva-
tion
%
Button and LED: Manual inclined plane
mode
&
Battery charge state LEDs
3.1.3 PRA 20 laser receiver control panel 3
@
On/off button
;
Volume button
=
Units key
%
Receiving area
&
Marking notch
(
Display
3.1.4 PRA 20 laser receiver display 4
@
Indicator showing distance from laser plane
;
Volume indicator
=
Rotating laser low battery indicator
%
Battery status
&
Indicator showing position of receiver
relative to height of laser plane
(
Display
)
Marking notch
+
Receiving area
