10 English 2081399
*2081399*
1. To insert, push the battery into the tool from the front until it engages with
an audible click.
2. To remove, press and hold down the release button and pull the battery
forward and out of the tool.
5.2 Fitting the belt hook (optional) 2
WARNING
Risk of injury. A falling power tool may present a risk of injury to yourself
and others.
▶ Check that the belt hook is fitted securely before beginning work.
The belt hook allows the power tool to be attached to a belt worn by
the operator. The belt hook can be fitted to allow attachment on the left
or right side of the body.
▶ Fit the belt hook.
5.3 Setting the torque
▶ Set the desired torque.
The torque is limited only when the power tool is set to screwdriving
mode .
5.4 Selecting the gear 3
▶ Select the desired gear by adjusting the two gear selector switches.
5.5 Setting forward or reverse rotation 4
An interlock prevents switching while the motor is running.
The control switch is locked when the forward/reverse switch is in the
middle position (safety lock).
▶ Set the forward/reverse switch to the desired direction of rotation.
5.6 Inserting/removing the accessory tool 5
1. Set the forward/reverse switch to the middle position or remove the
battery from the power tool.
Printed: 07.01.2019 | Doc-Nr: PUB / 5174907 / 000 / 02
