Hilti TE 2 - Tool Operation; Fitting the Side Handle; Chuck and Accessory Fitting; Hammer Drilling Operation

6 228074
*228074*
TE 2 TE 2-S TE 2M
Drilling diameter range
in concrete/masonry
(hammer drill bit)
3/16 in … 7/8 in 3/16 in … 7/8 in 3/16 in … 7/8 in
Drilling diameter range
in concrete/masonry
(hammer drill bit)
4 mm … 22 mm 4 mm … 22 mm 4 mm … 22 mm
Drilling diameter
range in wood
(solid)
3/16 in … 3/4 in 3/16 in … 3/4 in 3/8 in … 3/4 in
•/• •/• 3/16 in … 3/8 in
Drilling diameter
range in wood
(solid)
4 mm … 20 mm 4 mm … 20 mm 10 mm … 20 mm
•/• •/• 4 mm … 10 mm
Drilling diameter
range in metal
(solid-head drill
bit)
3/16 in … 1/2 in 3/16 in … 1/2 in 5/16 in … 1/2 in
•/• •/• 3/16 in … 5/16 in
Drilling diameter
range in metal
(solid-head drill
bit)
3 mm … 13 mm 3 mm … 13 mm 8 mm … 13 mm
•/• •/• 3 mm … 8 mm
Maximum length of the
depth gauge
7 in 7 in 7 in
Maximum length of the
depth gauge
180 mm 180 mm 180 mm
Operation
Fitting the side handle
CAUTION
Risk of injury! The depth gauge, if fitted but not used, might hinder the operator.
▶ Remove the depth gauge from the tool.
CAUTION
Risk of injury! Loss of control over the product.
▶ Check that the side handle is fitted correctly and tightened securely. Check that the
clamping band is engaged in the groove in the product.
2
TE 2-M
Fitting / removing the chuck
3
Fitting/removing the drill bit or other accessory: SDS chuck
Use of unsuitable grease may cause damage to the product. Use only the recom-
mended grease supplied by Hilti.
4
TE 2-M
Fitting/removing the drill bit or other accessory: Quick-release chuck
5
Adjusting the depth gauge
Always pay attention to the maximum length of the depth gauge.
6
Drilling with hammering action (hammer drilling)
7
