Hilti TE 2000-AVR Operating Instructions

128 ﻋﺮﺑﻲ 2154382
*2154382*
5.2.1ﺍﻟﻨﻘﺮﺑﺎﻹﺯﻣﻴﻞ
1.
ﺃﺩﺧﻞﺍﻟﻘﺎﺑﺲﺍﻟﻜﻬﺮﺑﺎﺋﻲﻓﻲﺍﻟﻤﻘﺒﺲ.
2.ﻗﻢﺑﺘﺮﻛﻴﺐﺍﻹﺯﻣﻴﻞﻓﻲﺍﻟﻮﺿﻊﺍﻟﻤﺮﻏﻮﺏ.
3.ﺍﺿﻐﻂﻋﻠﻰﻣﻔﺘﺎﺡﺍﻟﺘﺸﻐﻴﻞ/ﺍﻹﻳﻘﺎﻑ.
ﺇﺟﺮﺍءﺃﻋﻤﺎﻝﻓﻲﺩﺭﺟﺎﺕﺍﻟﺤﺮﺍﺭﺓﺍﻟﻤﻨﺨﻔﻀﺔ:
ﻳﺤﺘﺎﺝﺍﻟﺠﻬﺎﺯﻟﻠﻮﺻﻮﻝﺇﻟﻰﺣﺪﺃﺩﻧﻰﻣﻦﺩﺭﺟﺔﺣﺮﺍﺭﺓﺍﻟﺘﺸﻐﻴﻞﺣﺘﻰﻳﻌﻤﻞﺍﻟﻄﺎﺭﻕ.ﻟﻠﻮﺻﻮﻝﺇﻟﻰﺍﻟﺤﺪ
ﺍﻷﺩﻧﻰ،ﺿﻊﺍﻟﺠﻬﺎﺯﻋﻠﻰﺍﻷﺭﺿﻴﺔﻟﻔﺘﺮﺓﻗﺼﻴﺮﺓﻭﺍﺟﻌﻠﻪﻳﻌﻤﻞﻋﻠﻰﺍﻟﻮﺿﻊﺍﻟﻤﺤﺎﻳﺪ.ﻋﻨﺪﺍﻟﻠﺰﻭﻡ،ﻛﺮﺭﻫﺬﻩ
ﺍﻟﻌﻤﻠﻴﺔﺇﻟﻰﺃﻥﻳﻌﻤﻞﺍﻟﻄﺎﺭﻕ.
5.2.2ﺍﻹﻳﻘﺎﻑ
1.ﺍﺿﻐﻂﻋﻠﻰﻣﻔﺘﺎﺡﺍﻟﺘﺸﻐﻴﻞ/ﺍﻹﻳﻘﺎﻑ.
2.ﺍﺳﺤﺐﺍﻟﻘﺎﺑﺲﺍﻟﻜﻬﺮﺑﺎﺋﻲﻣﻦﺍﻟﻤﻘﺒﺲ.
5.2.3ﺇﺭﺷﺎﺩﺍﺕﺍﻟﻌﻤﻞ6
ﻳﻤﻜﻦﺿﺒﻂﺍﻹﺯﻣﻴﻞﻋﻠﻰ6ﺃﻭﺿﺎﻉﻣﺨﺘﻠﻔﺔ)ﻓﻲﺧﻄﻮﺍﺕﻣﻘﺪﺍﺭﻛﻞﻣﻨﻬﺎ60ﺩﺭﺟﺔ(.ﻭﺑﺬﻟﻚﻳﻤﻜﻦﺩﺍﺋﻤﺎ
ﺍﻟﻌﻤﻞﺑﺎﻹﺯﻣﻴﻞﺍﻟﻤﻔﻠﻄﺢﻭﺇﺯﻣﻴﻞﺍﻟﺘﺸﻜﻴﻞﻓﻲﻭﺿﻊﺍﻟﻌﻤﻞﺍﻟﻤﺜﺎﻟﻲﺍﻟﻤﻨﺎﺳﺐ.
◀ﺿﻊﺍﻹﺯﻣﻴﻞﻋﻠﻰﻣﺴﺎﻓﺔﺣﻮﺍﻟﻲ80-100ﻣﻢ)3¹⁄₈-4ﺑﻮﺻﺔ(ﻣﻦﺍﻟﺤﺎﻓﺔ.
◀
ﻓﻲﺣﺎﻟﺔﺃﻃﺮﺍﻑﻗﻀﺒﺎﻥﺣﺪﻳﺪﺍﻟﺘﺴﻠﻴﺢﻗﻢﺩﺍﺋﻤﺎﺑﺘﻮﺟﻴﻪﺍﻹﺯﻣﻴﻞﺟﻬﺔﺣﺎﻓﺔﺍﻟﺨﺎﻣﺔﻭﻟﻴﺲﺟﻬﺔﻗﻀﻴﺐﺣﺪﻳﺪ
ﺍﻟﺘﺴﻠﻴﺢ.
◀
ﺍﺑﺪﺃﻋﻤﻠﻴﺔﺍﻟﻨﻘﺮﺑﺎﻹﺯﻣﻴﻞﺑﺰﺍﻭﻳﺔﻣﻦ70°ﺇﻟﻰ80°ﺑﺎﻟﻨﺴﺒﺔﻟﺴﻄﺢﺍﻟﺨﺮﺳﺎﻧﺔﻭﻗﻢﺑﺘﻮﺟﻴﻪﺳﻦﺍﻹﺯﻣﻴﻞﺟﻬﺔ
ﺍﻟﺤﺎﻓﺔ.ﺛﻢﺣﺮﻙﺍﻟﺰﺍﻭﻳﺔﻓﻲﺍﺗﺠﺎﻩ90°ﻭﻗﻢﺑﺘﻜﺴﻴﺮﺍﻟﺨﺎﻣﺔ.
◀
ﺃﺩﺭﺍﻹﺯﻣﻴﻞﺑﺼﻮﺭﺓﻣﻨﺘﻈﻤﺔ،ﻧﻈﺮﺍﻷﻥﺍﻟﺘﺂﻛﻞﺍﻟﻤﺘﺴﺎﻭﻱﻳﺴﺎﻋﺪﻓﻲﻋﻤﻠﻴﺔﺍﻟﺸﺤﺬﺍﻟﺬﺍﺗﻲ.
◀ﺍﻟﻀﻐﻂﺍﻟﻀﺌﻴﻞﻟﻠﻐﺎﻳﺔﻳﺆﺩﻱﺇﻟﻰﺣﺪﻭﺙﻗﻔﺰﺍﺕﻟﻺﺯﻣﻴﻞ.ﺍﻟﻀﻐﻂﺍﻟﺰﺍﺋﺪﻟﻠﻐﺎﻳﺔﻳﺆﺩﻱﺇﻟﻰﺗﻘﻠﻴﻞﻗﺪﺭﺓ
ﺍﻹﺯﻣﻴﻞ.
6ﺍﻟﻌﺮﺑﺔﺍﻟﻨﺎﻗﻠﺔﻛﺘﺠﻬﻴﺰﺍﺧﺘﻴﺎﺭﻱ
6.1ﺍﻟﻨﻘﻞ
ﺗﻀﻤﻦﺍﻟﻌﺮﺑﺔﺍﻟﻨﺎﻗﻠﺔﻧﻘﻞﺍﻹﺯﻣﻴﻞﺍﻟﺪﻗﺎﻕﺑﺪﻭﻥﻣﺨﺎﻃﺮ.
•ﺍﻋﻤﻞﻋﻠﻰﺗﻮﻓﻴﺮﻭﺿﻊﻣﺴﺘﻘﺮﻟﻠﻌﺮﺑﺔﺍﻟﻨﺎﻗﻠﺔ.
•
ﺿﻊﺍﻟﺠﻬﺎﺯﻋﻠﻰﻃﺮﻑﺗﺮﻛﻴﺐﺍﻟﻤﺎﻛﻴﻨﺔﺍﻟﻤﺨﺼﺺﻟﺬﻟﻚ،ﻭﺍﺣﺮﺹﺩﺍﺋﻤﺎًﻋﻠﻰﺗﺄﻣﻴﻦﺍﻟﺠﻬﺎﺯﺃﺛﻨﺎءﻧﻘﻠﻪﺑﻮﺍﺳﻄﺔ
ﻣﺸﺒﻚﺍﻟﺘﺜﺒﻴﺖ.
•
ﺃﺩﺧﻞﺍﻹﺯﻣﻴﻞﻓﻲﺍﻟﺤﺎﻣﻞﺍﻟﻤﺨﺼﺺﻟﻪﺣﺘﻰﻳﺜﺒﺖ.
•
ﺗﺤﻘﻖﻣﻦﺃﻣﺎﻥﻃﺮﻕﺍﻟﻨﻘﻞ.
•
ﺍﺣﺮﺹﺃﻻﺗﺘﻮﻗﻒﺍﻟﻌﺮﺑﺔﺍﻟﻨﺎﻗﻠﺔﻋﻠﻰﺃﺳﻄﺢﻣﺎﺋﻠﺔ.
7ﺍﻟﻌﻨﺎﻳﺔﻭﺍﻟﺼﻴﺎﻧﺔ
ﺗﺤﺬﻳﺮ
ﺧﻄﺮﺑﺴﺒﺐﺣﺪﻭﺙﺻﺪﻣﺔﻛﻬﺮﺑﺎﺋﻴﺔﺇﺟﺮﺍءﺃﻋﻤﺎﻝﺍﻟﻌﻨﺎﻳﺔﻭﺍﻟﺼﻴﺎﻧﺔﺑﻴﻨﻤﺎﺍﻟﻘﺎﺑﺲﺍﻟﻜﻬﺮﺑﺎﺋﻲﻣﺮﻛﺐﻗﺪﻳﺘﺴﺒﺐﻓﻲ
ﺇﺻﺎﺑﺎﺕﺑﺎﻟﻐﺔﻭﺍﻹﺻﺎﺑﺔﺑﺤﺮﻭﻕ.
◀
ﺍﺣﺮﺹﻋﻠﻰﺳﺤﺐﺍﻟﻘﺎﺑﺲﺍﻟﻜﻬﺮﺑﺎﺋﻲﻗﺒﻞﺟﻤﻴﻊﺃﻋﻤﺎﻝﺍﻹﺻﻼﺡﻭﺍﻟﻌﻨﺎﻳﺔ!
ﺍﻟﻌﻨﺎﻳﺔ
•ﻗﻢﺑﺈﺯﺍﻟﺔﺍﻻﺗﺴﺎﺥﺍﻟﻤﻠﺘﺼﻖﺑﺤﺮﺹ.
•ﻗﻢﺑﺘﻨﻈﻴﻒﻓﺘﺤﺎﺕﺍﻟﺘﻬﻮﻳﺔﺑﺤﺮﺹﺑﺎﺳﺘﺨﺪﺍﻡﻓﺮﺷﺎﺓﺟﺎﻓﺔ.
•ﻧﻈﻒﺟﺴﻢﺍﻟﺠﻬﺎﺯﺑﺎﺳﺘﺨﺪﺍﻡﻗﻄﻌﺔﻗﻤﺎﺵﻣﺒﻠﻠﺔﺑﻌﺾﺍﻟﺸﻲء.ﻻﺗﺴﺘﺨﺪﻡﻣﻮﺍﺩﻋﻨﺎﻳﺔﺗﺤﺘﻮﻱﻋﻠﻰﺍﻟﺴﻴﻠﻴﻜﻮﻥ
ﻟﻤﺎﻗﺪﺗﺘﺴﺒﺐﻓﻴﻪﻣﻦﺍﻹﺿﺮﺍﺭﺑﺎﻷﺟﺰﺍءﺍﻟﺒﻼﺳﺘﻴﻜﻴﺔ.

Hilti TE 2000-AVR Specifications

General

Input power	2100 W
Power source	AC
Power plug type	Type C
Impact energy (max)	32 J
Idle impact rate (max)	1800 IPM
Vibration level (chiseling)	4.8 m/s²
Toolholder	- mm
Product color	Black, Red
Country of origin	Germany
Quantity per shipping (inner) case	1 pc(s)

Weight and Dimensions

Depth	731 mm
Width	574 mm
Height	146 mm
Weight	14500 g
Package depth	100 mm
Package width	150 mm
Package height	76 mm
Package weight	500 g
