HIMO ZB20 - Bicycle and Its Parts

10
Instrument
Shift lever set
Brake lever
Folding aheadset stem
Front light
Reflector, front wheel
Disc-Brake
Saddle
Tail light
Seat tube
Quick release of seat tube
Bicycle body folder
Battery compartment
Controller
Folding pedal
Ladder
Chain
Rear disc-brake
Motor
Rear derailleur
Reflector, rear wheel
Reflecting plate
1
2
3
4
5
6
7
8
9
10
11
No.
12
13
14
15
16
17
18
19
20
21
22
No.Description Description
Bicycle and its parts
This bicycle is suitable for use on auxiliary roads, public roads and trails. It can be folded with
existing joints and hinges in just a few simple steps. The necessary assembly materials are usually
included in the assembly list. Before riding for the first time, make sure that the safety equipment
is in place and in working condition. The materials need to be assembled by you or the bicycle
dealer.
