26
Component fixation
Recommended height of rider
61-69 cm/24-27 inches
66-76 cm/26-30 inches
71-79 cm/28-31 inches
76-84 cm/30-33 inches
79-86 cm/31-34 inches
81-89 cm/32-35 inches
86-94 cm/34-37 inches
37 cm / 14.5 inches
43 cm / 17 inches
45 cm / 18 inches
50 cm/19.5 inches
52 cm/20.5 inches
53-56 cm/21-22 inches
58-60 cm/23-23.5 inches
-
-
50 cm/19.5 inches
55 cm/21.5 inches
57 cm/22.5 inches
60 cm/23.5 inches
63 cm/25 inches
Road/travel bicycle
Recommended frame size
Mountain/Hybrid Bicycle
Recommended frame size
Rider's approximate leg length
Frame size guide
Please be sure to check the following items before riding and adjust according to the recommend-
ed torque:
The tightening of the screws/nuts of the bicycle brake system should ensure that all brake cables
are smooth. The recommended torque is 8-10N.m.
The tightening torque of the rear wheel of the bicycle should be no less than 30Nm, and the tighten-
ing torque of the front wheel should be no less than 25N.m.
The seat height can be adjusted by the seat post clamp. Pull off the seat post clamp and insert the
seat post at least to the minimum insertion limit marked on the seat post. Tighten the nut by twisting
the quick release lever of the seat post clamp, and then push the quick release lever to the closed
position.
The seat angle can be adjusted by the nut at the joint between the seat and the seat rail. Make sure
that the nut is tightened so that the seat will not move forward or backward when sitting on it.
The total allowable load of this bicycle (including the rider) is 100 kg.
The net weight of this bicycle is approximately 28 kg.
This bicycle is not designed to be equipped with a trailer.
Minimum 160 cm
Maximum 190 cm
