Himoinsa CEA7 User Manual

(APPENDIX I) PARAMETERS TABLE | PAGE 67
Value Function
32..95 Unit alarm (see Table of Programmable output genset alarms allocation)
96 Stabilized engine
97 Fumes control
98 Mains present
99..130 Unit alarm (see Table of Programmable output genset alarms allocation)
131 YANMAR oil pump
132 Input Set 1 (See Section 4.11)
133 Input Set 2 (See Section 4.11)
134 Input Set 3 (See Section 4.11)
135 Input Set 4 (See Section 4.11)
Tabla 10
Programmable control unit functions
Valor Function
0 Not programmed
2 2-BPA
3 3-ATA
4 4-NA
5 5- ENT4
6 6- ENT5
8 8-ENT1
9 9-ENT2
10 10-ENT3
13 13-ENT P
14 14-ENT T
15 15-ENT C
17 Extension ENT 1.1 (CCPT100 or CCIn8 ID 0, input 1) (See Section 5.8)
18 Extension ENT 1.2 (CCPT100 or CCIn8 ID 0, input 2) (See Section 5.8)
19 Extension ENT 1.3 (CCPT100 or CCIn8 ID 0, input 3) (See Section 5.8)
20 Extension ENT 1.4 (CCPT100 or CCIn8 ID 0, input 4) (See Section 5.8)
21 Extension ENT 1.5
(CCIn8 ID 0, input 5) (See Section 5.8)
22 Extension ENT 1.6
(CCIn8 ID 0, input 6) (See Section 5.8)
Tabla 9
Programmable control unit outputs
Value Function
0 Not programmed
1 RC input
2 BP input
3 AT input
4 NA input
5 ENT4 input
6 ENT5 input
7 PE alarm
8 ENT1 input
9 ENT2 input
10 ENT3 input
11 Heating resistance
12 Block mode
13 Manual mode
14 Auto mode
15 Test mode
16 Alternator alarm
17 Alarm 1
18 Alarm 2
19 Alarm 3
20 Alarm 4
21 Alarm 5
22 Dummy load
23 Thermal protection
24 Load demand
25 HOLD control engine
26 Gas valve (only gas engine)
27 Unit contactor opening
29 Unit contactor status
30 Network contactor status (only automatic control unit)
31 Watchdog
