Himoinsa CEA7 User Manual

(APPENDIX I) PARAMETERS TABLE | PAGE 68
Tabla 11
Programmable output genset alarms allocation
Index Alarm
32 Water temperature
33 Oil pressure
34 Emergency stop
35 Alternator batteries
36 Starting failure
37 Water level
38 Fuel reserve
39 Overspeeding
40 Under Speed
41 Overload
42 Asymmetry
43 Maximum genset voltage
44 Maximum genset frequency
45 Phase sequence
46 Reverse Power
47 Battery voltage
48
Water temperature (sensor)
49 Oil pressure (sensor)
50 Fuel level
51 Short Circuit
52 Minimum genset voltage
53 Minimum genset frequency
54 Unexpected stop
55 Stop failure
56 Low Engine Temperature
57 Unit failure
58 Programmable 1
59 Programmable 2
60 Programmable 3
61 Com switching
62 Rental counter
63 Maintenance counter
64 Programmable 4
65
Programmable 5
66 Auxiliary battery
67 Battery high voltage
68 Start battery low voltage
69 Genset contactor
70 Unit power
71 Temperature probe 1
72 Temperature probe 2
73 Temperature probe 3
74
Temperature probe 4
75 J1939
76 Temperature probe 1
Valor Function
23 Extension ENT 1.7
(CCIn8 ID 0, input 7) (See Section 5.8)
24 Extension ENT 1.8
(CCIn8 ID 0, input 8) (See Section 5.8)
25 Extension ENT 2.1 (CCPT100 or CCIn8 ID 1, input 1) (See Section 5.8)
26 Extension ENT 2.2 (CCPT100 or CCIn8 ID 1, input 2) (See Section 5.8)
27 Extension ENT 2.3 (CCPT100 or CCIn8 ID 1, input 3) (See Section 5.8)
28 Extension ENT 2.4 (CCPT100 or CCIn8 ID 1, input 4) (See Section 5.8)
29 Extension ENT 2.5 (CCIn8 ID 1, input 5) (See Section 5.8)
30 Extension ENT 2.6
(CCIn8 ID 1, input 6) (See Section 5.8)
31 Extension ENT 2.7
(CCIn8 ID 1, input 7) (See Section 5.8)
32 Extension ENT 2.8 (CCIn8 ID 1, input 8) (See Section 5.8)
33 Extension ENT 3.1 (CCPT100 or CCIn8 ID 2, input 1) (See Section 5.8)
34 Extension ENT 3.2 (CCPT100 or CCIn8 ID 2, input 2) (See Section 5.8)
35 Extension ENT 3.3 (CCPT100 or CCIn8 ID 2, input 3) (See Section 5.8)
36 Extension ENT 3.4 (CCPT100 or CCIn8 ID 2, input 4) (See Section 5.8)
37 Extension ENT 3.5
(CCIn8 ID 2, input 5) (See Section 5.8)
38 Extension ENT 3.6
(CCIn8 ID 2, input 6) (See Section 5.8)
39 Extension ENT 3.7
(CCIn8 ID 2, input 7) (See Section 5.8)
40 Extension ENT 3.8 (CCIn8 ID 2, input 8) (See Section 5.8)
41 Extension ENT 4.1 (CCPT100 or CCIn8 ID 3, input 1) (See Section 5.8)
42 Extension ENT 4.2 (CCPT100 or CCIn8 ID 3, input 2) (See Section 5.8)
43 Extension ENT 4.3 (CCPT100 or CCIn8 ID 3, input 3) (See Section 5.8)
44 Extension ENT 4.4 (CCPT100 or CCIn8 ID 3, input 4) (See Section 5.8)
45 Extension ENT 4.5
(CCIn8 ID 3, input 5) (See Section 5.8)
46 Extension ENT 4.6 (CCIn8 ID 3, input 6) (See Section 5.8)
47 Extension ENT 4.7
(CCIn8 ID 3, input 7) (See Section 5.8)
48 Extension ENT 4.8
(CCIn8 ID 3, input 8) (See Section 5.8)
49 Input Set 1 (See Section 4.11)
50 Input Set 2 (See Section 4.11)
51 Input Set 3 (See Section 4.11)
52 Input Set 4 (See Section 4.11)
